GARLOCK BLUEGARD 3400





Style 3400 gasket sheet provides excellent sealability and drastically lowered emission levels. Constructed from aramid fibers and an SBR binder style 3400 serves in water, inert gases, and saturated steam applications (saturated steam under 150psi).

Tensile Strength (psi):2250

Temperature MAX: 400 degrees F continuous, 700 degrees F maximum

Pressure MAX: 1200 psi

P x T Max: 1/32", 1/16" 350,000, 1/8" 250,000

Density: 100 lbs/cubic ft

Color: Grey/Black, branded

Weight (SF, 1/8”): .988 lbs

ASTM-D-F104 Call Out: F712902A9B4E45K5L102M9
